SAM9X60 Curiosity Development Board

Last modified by Microchip on 2024/06/20 12:43

Contents



In this training, we introduce the SAM9X60 Curiosity Development Board. The SAM9X60 Curiosity is designed for evaluating and prototyping with the high-performance, ultra-low power SAM9X60 ARM926EJ-S based microprocessor (MPU) running up to 600 MHz which can be used to develop embedded Linux® or Real-Time Operating System (RTOS) applications.

SAM9X60 Curiosity Development Board

Comparison

To compare the SAM9X60 Curiosity with the SAM9x60-EK Evaluation Kit, see the "SAM9X60 Curiosity Development Board - Comparison" page.

Back to Top

What Can I Do With the SAM9X60 Curiosity?

The SAM9X60 Curiosity is designed for evaluating and prototyping with the high-performance, ultra-low power SAM9X60 ARM926EJ-S based microprocessor (MPU) running up to 600 MHz. You can use it to develop embedded Linux or RTOS applications.

For information on Microchip's MPU offerings, visit the MPUs product page.

Back to Top

What is the SAM9X60 Curiosity?

The SAM9X60 Curiosity is a multi-function demonstration and development platform featuring:

  • SAM9X60D1G MPU
  • Mass storage
  • Communications
  • Debugging
  • User interface
  • Expansion
  • Power options

Back to Top

How Do I Get Started?

Start by reviewing the "SAM9X60 Curiosity Development Board - Features" page and then jump to the "SAM9X60 Curiosity Development Board - Booting Demo Linux Image" page.

Back to Top

Where Can I Get Demo Images?

Demonstration images for the SAM9X60 Curiosity are available on the Linux4SAM website. Images are available from the following build automation systems:

Back to Top

How Do I Write Images?

Demonstration images can be flashed onto a microSD memory card (of size 1 GB or higher) using the balenEtcher, a cross-platform utility program for writing image files onto storage media.

You can alternatively write an image to the onboard NAND Flash memory. This is done using the SAM-BA® In-System Programmer (ISP) utility.

For more information on writing demonstration Linux images, see the "SAM9X60 Curiosity Development Board - Booting Demo Linux Image" page.

Back to Top

How Do I Develop?

There are two popular development methods, they are:

Back to Top

Where Can I Get Source Code?

Source code is available for the SAM9X60-Curiosity at the Linux4SAM GitHub repository.

Back to Top

How Do I Debug?

JTAG

A JTAG interface to the SAM9X60-Curiosity is provided by 20-pin connector J12 (not populated). This facilitates software development and debugging by connecting an external JTAG debugger such as the J-32 Debug Probe or Segger J-Link BASE Debug Probe.

Console Serial Port

A console serial port is available using the Debug Universal Asynchronous Receiver Transmitter (UART) port. The SAM9X60 features a dedicated serial UART port (J11) (3.3 VDC TTL level) for communicating with the target console where you can:

  • View the kernel log
  • Query processes
  • Get information on various internal features of the system

See the "SAM9X60 Curiosity Development Board - Console Serial Communications" page for more information about the Linux console.

Back to Top

Is There Any Additional Information?

Additional information can be found on the SAM9X60 Curiosity product page. There you can find:

  • User’s Guide
  • Design Files
  • Manufacturing Files
  • Links to component datasheets

Back to Top

Where Can I Order One?

You can purchase a SAM9X60 Curiosity (Part Number: EV40E67A) from the Microchip Purchasing and Client Services page or your favorite Microchip distributor.

Back to Top

What Is Included in the Box?

Contents of the box are:

  • The SAM9X60 Curiosity Development Board
  • USB Type-A to USB Micro-B cable

Back to Top

What Do I Need To Supply?

For booting demo Linux images, you will need to supply:

  • Personal computer (Windows®, macOS®, Linux) running a terminal program
  • USB-to-Serial 3.3 VDC TTL Level adapter with a 6-pin single-in-line 0.1” pitch connector
  • SD memory card (1 GB or larger)

Back to Top

What's Next?
